Adaptor for COBs
Article number:
47.919.E301-0
EAN:
-
Product information "Adaptor for COBs"
Screw mounting: for screws M3 and locking washer
Max. torque for screw fixing 0.5 Nm*
Strip length: 7-1 mm
Polarity of LED must be observed
Specifications of LED manufacturer must be observed
cURus: For limited applications
VDE-Reg. No. E289
*Please note the max torque of the COB manufacturer
Max. torque for screw fixing 0.5 Nm*
Strip length: 7-1 mm
Polarity of LED must be observed
Specifications of LED manufacturer must be observed
cURus: For limited applications
VDE-Reg. No. E289
*Please note the max torque of the COB manufacturer
| LED?: | 1 |
|---|---|
| Material: | PC |
| Note warranty conditions: | *Warranty conditions of BJB GmbH & Co. KG as stated as available via the Internet under https://www.bjb.com/en/legal-information/general-terms-and-conditions/ are valid. |
| Packaging quantity: | 500 |
| Pre-centering for COB: | Yes |
| Prefixation: | Stranglepins |
| Producttype: | Spotlight Connectors and Accessories |
| Series: | COB Connectors - 47.319 |
| Suitable for: | Adaptor for COBs Vero 18 from Bridgelux |
| UL: | yes |
| Weight: | 5 g |
| approbation: | cURus |
| mounting method 1: | Screw mount |
| old article number: | 47.919.-301.50 |
